PE double wall corrugated pipe extrusion machine from China manufacturer - Qingdao Benice Plastic Machinery Co., Ltd.

PE double wall corrugated pipe extrusion machine

Price:	20000.0~100000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SJ90/33

Production Capacity: 3-5sets/month

Delivery Date: within 35 working days

Use: Plastic Pipe Crusher

Brand Name: BENICE

Capacity: 200KG/H

BRAND NAME: BAX

Means of Transport: Ocean,Land

Packing: packing in film or wood cas...

Plastic Type: PP/PE

Shaft Design: Single

Power: 55KW

PROCESSING TYPE: CORRUGATED PIPE EXTRUDER

well-designed developed, It is not afraid of acid, corrosion resistance and good sealing, no water seepage, high ring stiffness, friction coefficient

PE Double-wall corrugated pipe equipment
PE PVC Double-wall corrugated pipe production line is on the basis of absorbing foreign advanced technology and manufacturing processes, well-designed developed, It is not afraid of acid, corrosion resistance and good sealing, no water seepage, high ring stiffness, friction coefficient, anti-aging, anti-electric erosion, softness and good features Applications for wires, cables threading pipe, washing machine drains, vacuum cleaner tubes, ventilation tubes, etc

Adopt to PLC control system it is more accurate more intellectualize control order makes the operation more simple.
The production line is the single screw extruder in high efficiency, has the independent water and air circular system and form the double wall corrugated pipe by cooling water and compress air.
Corrugated forming system with strong cooling ability operation more simple efficiency,
The mould surface is nitrided, has the adjust equipment to adjust the wall thickness, it suitable for different diameters pipes.
Extruder has air cooling and water cooling function.

Keywords: pvc double wall corrugated pipe line, pvc double wall corrugated pipe making machine, pvc double wall corrugated pipe extruding machine, pvc double wall corrugated pipe making line

PE/PVC Corrugated pipe production line

There are double wall and single wall corrugated pipe production lines, the pipes widely used in the electrical field, and construction field.

Spections of the corrugated pipe production line:

High precision and character for forming machine and head die.
Water and wind cooling for module
On-line belling
Unique digital control system
High automatic, high output, stable production condition.
Easy operation methods, and high technical automatic
Competitive price with nice after-selling service
Durable using life

Single Wall Corrugated Pipe Production Line
Extruder types	BAXSJ-65/25	BAXSJ-90/25	BAXSJ-120/25
Range of Pipe Dia.	Φ16-50 (mm)	Φ65-115 (mm)	Φ115-175 (mm)
Water Consumption	2000 (L/H)	4000 (L/H)	5000 (L/H)
Water Pressure	0.4-0.6 (Mpa)	0.4-0.6 (Mpa)	0.4-0.6 (Mpa)
Number of Mold Blocks	40 (Pairs)	50 (Pairs)	60 (Pairs)
Total Length of Mold Blocks	2400 (mm)	5180 (mm)	6216 (mm)
Speed of Mold Blocks	1-8 (m/min)	1-12 (m/min)	1-8 (m/min)
Dimensions(L×W×H)(Approx)	10×1.25×1.5(M)	18×1.35×1.7(M)	21×1.55×2.2(M)
Total Weight (Approx)	3 (Ton)	6 (Ton)	9.5 (Ton)

Double Wall Corrugated Pipe Production Line
Model		BAX×1500	BAX×1000	BAX×500	BAX×250	BAX×160	BAX×90
Structure Form		Vertical	Vertical	Horizontal	Horizontal	Horizontal	Horizontal
Applicable Raw Materials		HDPE	HDPE	HDPE	HDPE	HDPE	HDPE
Pipe Diameter Range(mm)	ID(mm)	Φ400	Φ250	Φ160	Φ90	Φ75	Φ40
Pipe Diameter Range(mm)	OD(max)	Φ1500	Φ1000	Φ500	Φ250	Φ160	Φ90
Max. Extrusion Output (kg/h)		1200	850	600	350	200	100
Expansion Mode		Belling on-line, double-wall Socket Joint	Belling on-line, double-wall Socket Joint	Belling on-line, double-wall Socket Joint
Forming Speed(m/min)		0.25-2.5	0.25-2.5	0.4-4	0.5-5	0.6-6	0.8-8
Axis Height(mm)		1600	1600	1150	1100	1000	1000
Number of Mold Blocks (pairs)		42	42	40	48	57	48
T, otal Installed Power(kw)		820	660	385	240	150	95
